Lifetime 6417 - Page 22

22
Hardware shown at 50% of actual size )BSEXBSFTIPXOBUPGBDUVBMTJ[F
CJRY
Door Frame Support Bracket
BBN (x1)
Carriage Latch
BOX 4 (CONT.)
BOX 5
DOOR FRAME & DOOR INSTALLATION HARDWARE [BNE] (CONT.)
DOOR WINDOW INSTALLATION HARDWARE [BNC]
ADZY
1/4” x 5/8” Pan-Head Screw
AGZY
3JHIU$FOUFS%PPST
BLOY
Door Window
AGO (x1)
Left Door
Hardware shown at actual size
Parts shown at 4% of actual size
PARTS & HARDWARE IDENTIFIER
