Lifetime 6417 - Page 25

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
25
SEC
8d 1 1/2” Common NailY
48” x 96” x 3/4” Treated PlywoodY
27 1/2” x 96” x 3/4” Treated PlywoodY
27 1/2” x 27 1/2” x 3/4” Treated Plywood (x1)
1
SEC
1.3
SEC
1.4
ALTERNATIVE SITE PREPARATION: OPTION 1 - WOOD PLATFORM ASSEMBLY (CONT)
Square up the frame by measuring from corner to corner. Measurement A should equal Measurement B.
Cut Plywood into sizes called for on previous page. Arrange the Plywood according to the diagram and nail into
QMBDFXJUIEYwOBJMT1MBDFQMBUGPSNJOUIFEFTJSFEMPDBUJPO*GQMBUGPSNEPFTOPUSFTUMFWFMPOUIFHSPVOE
build up low points with loose dirt until platform is stable.
Note: All lumber must be rated for outdoor use.
!
96” x 48”
96” x 48”
96” x 27 1/2”
27 1/2” x 27 1/2”
96” x 27 1/2”
B
A
