Lifetime 6417 - Truss and Wall Channel Assembly

31
20 1/8”
71 11/16”
79 1/2”
79 1/2”
7/16” WrenchY
TRUSS & WALL CHANNEL ASSEMBLY
HARDWARE REQUIRED
METAL PARTS REQUIRED
TOOLS REQUIRED
SEC
Safety Glasses
AFP (x8)
Truss Support Strip
AIP (x4)
5SVTT(VUUFS$POOFDUPS
AHT (x8)
Floor Bracket
AFH (x8)
5SVTT(VUUFS$IBOOFM
AFG (x4)
Truss Brace Channel
AFQ (x8)
Wall Support Channel
AAK (x40)
wYw)FY#PMU
ADJ (x40)
1/4” Cap Nut
Parts shown at 8% of actual size
Hardware shown at actual size Hardware shown at 50% of actual size
HARDWARE BOX REQUIRED: BGV (x4)
3
METAL PARTS KITS REQUIRED: BNN, BNF, BNG, BNL, BNK
