Lifetime 6417 - Page 38

38
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
ADZY
AHD
AHD
SEC
Install the next Wall Panel at the left, rear corner of the Shed and connect the two rear, corner Wall Panels (AHD)
XJUIB$PSOFS$IBOOFMBOEUXFMWF1/4” x 5/8” Phillips Pan-Head Screws (ADZ). Connect the next Wall Panel
using six (6) 1/4” x 5/8” Phillips Pan-Head Screws (ADZ).
SEC
Finally, install the last Window Wall Panel (AHH) and Wall Panel (AHD)UPUIF4IFEVTJOHUXFMWF1/4” x 5/8” Phillips
Pan-Head Screws (ADZ).
Note: A second adult should apply pressure to the opposite side of the wall for easy insertion of screws.
!
AHD
AHH
4
4.6
4.7
