Lifetime 6417 - Right Door Assembly

53
Safety Glasses
Needle-Nosed Pliers
RIGHT DOOR ASSEMBLY
HARDWARE REQUIRED
METAL PARTS REQUIRED
PLASTIC PARTS REQUIRED
TOOLS REQUIRED
SEC
#2 Phillips Screwdriver
ADZ (x9)
1/4” x 5/8” Phillips Pan-Head Screw
AEEY
Yw'MBU8BTIFS
ADW (x4)
Yw1IJMMJQT1BO)FBE4DSFX
Part shown at 8% of actual size
Part shown at 4% of actual size
Hardware shown at actual size
)BSEXBSFTIPXOBUPG
actual size
Hardware shown at 15% of
actual size
Hardware shown at 50% of
actual size
BLH (x1)
Extended Door End Channel
AFBY
Door Brace
AGZ (x1)
Right Door
(The Right and Center Doors are the same part)
BQQY
wYw$BSSJBHF#PMU
7/16” Wrench
ADJY
1/4” Cap Nut
26 1/4”
AIK (x1)
Right Door Handle
AIO (x1)
AHW (x1)
Thumb Lever
ExtensionAHY (x1)
Latch Spring
AHV (x1)
Extended
Door Latch
AIL (x1)
Right Door Lock
Bracket
AHX (x1)
Latch Cover Plate
ADB Y
wYw4QBDFS
AEB Y
1/4” Flat Washer
77 13/16”
1 1/2”
HARDWARE BAG REQUIRED: BMU
LOCATED IN BOX 1 AND METAL PARTS KIT: BNN
LOCATED IN BOX: 5
8
