Ensure you use the correct Hinge Assembly for the Left and Right Doors. The hinge faces outward on each
door, and the head of the hinge pin always goes on top.
Use these holes when
connecting the Left and
Right Doors to the Hinge
Assemblies.
Left Door Hinge
Right Door Hinge
Hinge faces outward and head
of hinge pin goes on top.
Hinge faces outward and head
of hinge pin goes on top.
10
NO HARDWARE REQUIRED FOR THIS PAGE
