Lifetime 6417 - Page 63

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
63
SEC
10
7.4
7.4
7.1
7.1
SEC
10.5
SEC
10.6
Secure a Corner Frame Bracket (BLI) to the Corner Door Frame and Left Hinge Assembly using the required
hardware.
Slide the Center Door Assembly down through the channel of the Door Hinge End Channel, as shown.
BBLY
BLI
BBL
BBL
AEB
AEB (x1)
CENTER DOOR ASSEMBLY
7/16”
