Lifetime 6417 - Page 66

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
66
SEC
10
ADJ (x4)
ADJ
ADJ
ADJ
ACA
ACA
BLL
BLM
BLN
ACA
ACA (x4)
7/16”
7.1
7.1
SEC
10.11
SEC
10.12
Slide the Long Glider Track (BLL) next to the Short Glider Track (BLM).
Notch
Align the square holes in the two Tracks with the square holes in Glider Track Extension (BLN) and connect the
three pieces using the required hardware.
