Lifetime 6417 - Page 85

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
85
SEC
14
AGQ or AHB
ADZ
ADZ
AFL
Fit three Roof Support Strips (AFL) (dark gray) into the slots (light gray) in the Center Roof Panels and Roof Panels for Domed
Skylight as you put them in place.
AFL (x4)
28 7/8”
ADZY
SEC
14.3
*OTUBMMUXPInner Roof Panels (AGQ) and four (4) Roof Support Strips (AFL) to the Shed as shown. Roof Panels for
Skylights (AHB) can be inserted into any of the center Roof Panel sections.
Note: This section applies to the two types of Roof Panels: Inner Roof Panel (AGQ) and Roof Panel for Domed Skylight (AHB).
!
Note: The holes in the Roof Support Strips are for manufacturing purposes only.
!
AFL
