99
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
ADW
ADW (x10)
(Not all screws are used)
AFU
SEC
SEC
Using a Level, position the Pegboard Strip (AFU) in the desired location. Screw the Pegboard Strip to the Wall
using fi ve (5) #10 x 3/4” Phillips Pan-Head Screws (ADW). See Note.
Insert Hooks (AIF, AIG, AIH, AII, and AIJ).
PEGBOARD STRIP INSTALLATION
Note: The Pegboard Strip is screwed directly into the plastic. Line up the Strip anywhere on Wall so holes are over plastic (and not over a groove in
the Wall).
!
Note: Ensure the Pegboard Strip is level before inserting Screws.
!
17
17.3
17.4
ADZ (x4)
To Next Page
