Lifetime 6418 - Install Doors and Front Gable; Hang Doors and Secure Front Gable

21
10
One person should hold doors in place
until they are secured with the front
Gable.
Install Doors and Front Gable
HV
Use pliers to bend
back the ends of
the Cotter Pins (HV)
after they have been
inserted.
10.5: Insert the Door Hinge Cotter Pin (HV) through the Bushings and Hinges on both Doors.
Be sure that these two holes line
up, so that the Cotter Pin (HV)
can be inserted.
10.3: Push a Door Hinge Bushing (HU) up through the hole in the fl oor.
10.4: Hang the Right Door on the right front corner. Make sure bottom of
Hinge pin fi ts into the Bushing.
10.1: Push a Door Hinge Bushing (HU) up through the hole in the fl oor.
10.2: Hang the Left Door on the left front corner. Make sure bottom of
Hinge Pin fi ts into the Bushing.
Hardware Bags: 1033168
HU (1)
(Not Actual Size)
Hardware Bags: 1033168
HU (1)
HV (2)
(Not Actual Size)
(Not Actual Size)
HU
HU
