Lifetime 71546 - Page 19

19
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
ADSY
Align the hole in the Top Pole (ALH) with the slot in the .JEEMF1PMF"-' and
slide the Top Pole over the Middle Pole. Insert a 1/4” x 3/4” Screw (ADS)
through the Domed Countersink Washer (CIH) and the small hole in the Top
Pole and into the slot in the Middle Pole as shown.
SEC
1.3
ALH
"-'
Note: The 1/4” x 3/4” Screw should be fl ush with the Pole, but
will spin freely once installed. Do not jam the Poles together
until instructed.
!
ADS
ALH
"-'
CIHY
CIH
