20
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
Align the hole in the .JEEMF1PMF"-' with the slot in the Bottom Pole (ALE) and
slide the Middle Pole over the Bottom Pole. Insert a 1/4” x 3/4” Screw (ADS)
through the Domed Countersink Washer (CIH) and the small hole in the Middle
Pole and into the slot in the Bottom Pole as shown.
SEC
1.4
Note: The 1/4” x 3/4” Screw should be fl ush with the Pole, but
will spin freely once installed. Do not jam the Poles together
until instructed.
!
"-'
ALE
ADSY
CIHY
ADS
"-'
ALE
CIH
