Lifetime 71546 - Page 44

44
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
5.9
ALM
ALH
7”
(Not actual length)
ABBY
AAZY
9/16”Y
Insert the Pole Cap (ALM) into the Top Pole (ALH) as shown.
SEC
5.10
Note: Tighten the 3/8” Centerlock Nut until it is fl ush with the end of the Bolt.
!
AAZ
ABB
AKC AKC
Insert the 3/8” x 7” Hex Bolt (AAZ) through the holes in the Short Extension
Arms (AKC)UIBUBSFDMPTFTUUPUIF1PMF4FDVSFUIFwYw)FY#PMUUP
UIF4IPSU&YUFOTJPO"SNTXJUIUIF3/8” Centerlock Nut (ABB).
