5
AD
RG
RF
RH
STEP 1A
RC
RG
RF
RH
Required for this page:
HD9136B
(2)
(2)
(4)
(2)
RC
AH
OPTION 2
THIS OPTION IS FOR ASSEMBLY WITHOUT A U-BOLT.
1/2” Wrench
NOTE: The Backboard Brackets shown are Lifetime Products
®
models
and are for illustration purposes only. If using Brackets other than
the Lifetime Products
®
models shown here, refer to the instructions
provided with the Brackets.
Lay the Backboard (AB) on a
table or bench.
The 5/16” x 5” Hex Bolts (RG)
go through the upper holes in the
Backboard.
Only hand tighten the Nuts (RH) now.
RE
(2)
RE
RE
STEP 1B
Slide the Carriage Bolt (RE)
into the crimped slot in each
Backboard channel.
RH
RH
STEP 1C
RE
To finish the assembly, turn to Page 6
Bend the Backboard Brackets
out so the lower holes go over
the Carriage Bolts.
Do not overtighten these
Nuts (RH).
Completely tighten the Nuts
(RH) from Step 1A.
AB
To Next Page
