Lifetime 90136 - Section 1.9: Attaching Handholds

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
19
Attach Handholds (CPB)TOEACHOFTHEJOINTSNOTTOUCHINGTHEGROUND
Attach the handholds by sliding a Washer (ARL) over the v"OLT
(ASI)ANDPLACINGTHE(ANDHOLDOVERTHE"OLTIt is critical that the
Washer is added,INEUPTHENOTCHONTHEBOTTOMOFTHE(ANDHOLD
WITHTHETUBEONTHETOPOFTHEJOINT3ECUREEACH(ANDHOLDWITHA
Washer and 5/16” Nylock Nut (ASE). Tighten completely.
SEC
1.9
WARNING
"EFOREALLOWINGCHILDRENPLAYENSURE
handholds are in place and secure. Replace
BROKENHANDHOLDSIMMEDIATELYDONOTALLOW
children to play on damaged equipment.
Note: When moving the Geo-Dome, do not slide the Dome or tip it
on its side. This may cause the Dome to lose its shape. Instead, use
several people to lift the Dome and move it to the new location.
!
3/16”
1/2”
Handhold notch fits over
the top of the Tube joint
ARL X
CPB
ARL
ARL
ASI
ASEX
