Lifetime 90136 - Section 1.8: Top Green Tubes

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
18
Connect the five Green Tubes (CPC) at the top by sliding a 5/16” x v
Bolt (ASI) through a Washer (ARL)ANDTHROUGHTHElVE'REEN4UBESIN
the order shown. Secure with a Washer and 5/16” Standard Nut (ATL).
Tighten completely.
SEC
1.8
4
5
3
2
CPC
CPC
CPC
CPC
CPC
1
CAUTION
#HECKANDTIGHTENALLBOLTSBEFOREALLOWING
children to play. Do not allow Children to play on
THE'EO$OMEBEFORETHEHANDHOLDSAREINPLACE
3/16”
1/2”
ARL X
ATLX
ASIX
