37
TOOLS AND HARDWARE REQUIRED
X SECTION 5 (CONTINUED)
5.5
• Attach the Deck Support Assembly to the A-Frame Assembly using the hardware indicated. Insert a Rectangular
Tube Plug (EII) in each end of the Deck Support Tube, Swing-side (CBD) once hardware is secure. Repeat this on the
opposite side of the assembly to secure the Deck Support Assembly to both Poles.
!
• This step requires two people.
DSA (x2)
BTS (x2)
EII (x2)
3/16 in/po (≈5 mm)
(2)
CBD
EII
DSA
BTS
To Next Page
