TOOLS AND HARDWARE REQUIRED
X SECTION 8 (CONTINUED)
6
8.4
• Attach the Roof Panels (CCC) to the Roof Trusses (CCA), and secure the panels as shown. The notch at the top of
the panel will line up with the top of the Trusses.
ADV (x24)
(1)
(1)
The Roof Panels placed on top need to have a notch as shown.
ADV
CCC
CCC
ADV
ADV
ADV
ADV ADV
ADV ADV
ADV
ADV
ADV ADV
WARNING
Use extreme caution when standing on ladders to
perform assembly steps. Follow all warnings and
cautions on the ladder. Failure to follow all of these
instructions and warnings could lead to serious
personal injury or property damage.
!
CAUTION
Do not overtighten. Overtightening may damage
parts and void warranty.
