13
TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS / INSTRUMENTAL Y HERRAJE REQUERIDOS
SECTION 2 (CONTINUED) / SECTION 2 (SUITE) / SECCIÓN 2 (CONTINUACIÓN)
2.3
• Set the rim bracket (HJY) into the recess on the back of the backboard (AJI) as indicated.
• Mettre le support de l'anneau (HJY) dans le renfoncement sur l'arrière du panneau (AJI) comme indiqué.
• Colocar el soporte del aro (HJY) en el hueco en la parte trasera del tablero (AJI) como se indica.
•
Recess
•
Renfoncement
•
Hueco
HJY
AJI
