Liftkar PTR - Start-Up and Assembly; Battery Charging; Handle Unit Assembly and Locking

Liftkar PTR I 12
3 START-UP
FIRST STEPS
3.1 CHARGE BATTERY
Fully charge the 24V/12Ah battery pack installed in the base unit. This
can take up to 6 hours depending on the residual charge. The charging
socket is located on the back of the base unit (figure 1a).
Liftkar PTR is equipped with an inbuilt battery charger. During charging
process a LED (figure 1b) which you can find in the left side wall of the
device chassis indicates the charging level:
Orange: charging process running
Green: charging process terminated, fully charged batteries
3.2 INSERTING / LOCKING THE HANDLE UNIT TO THE BASE
UNIT
Place the U-shaped yoke on the underside of the handle unit on the
round support bar in the base unit (figure 2a).
Make sure that the yoke engages with the grooves of the support bar
(figure 2b). By pivoting the handle unit for- / backwards the engagement
is facilitated.
3.3 LOCKING THE HANDLE UNIT
Pivot the handle unit into the operating position. The spring-loaded
retention lever engages automatically. Additionally, the safety lug holds
the retention lever in position (figure 3).
WARNING
Before operating the tracked stairclimber always control
the position of the retention lever. The safety lug must be
engaged!
