Liftkar PTR - Controls - Base Unit; Liftkar Ptr - Individual Components; Technical Data

Liftkar PTR I 9
2.2 CONTROLS - BASE UNIT
KEY
The key protects the LIFTKAR PTR against
unauthorised use.
ON/OFF
Same function as on handle unit.
WARNING
Use only for loading purposes (e.g.
stowing in car).
DRIVE
Starts the drive chain in the chosen climbing mode.
SPEED
Preselect switch for stair climbing speed
Speed I ..................... 5,5m/min
Speed II ................... 6,5m/min
Speed III ................... 7,5m/min
2.3 LIFTKAR PTR – INDIVIDUAL COMPONENTS
LIFTKAR PTR – COMPONENTS (SCOPE OF DELIVERY)
2.4 TECHNICAL DATA
Maximum load
(incl. wheel chair)
130 kg / 160 kg
Minimum wheel chair width
(frame inside)
420 mm
Max. inclination 35°
Total weight 39 kg
Weight of base unit
(incl. batteries)
28 kg
Range up to 1000 steps *
Minimum landing space 970 x 970 mm
Sound pressure level below 80dB
* depending on overall weight to be transported
