LIGHT MY BRICKS 10317 - Page 35

INSTRUCTIONS 35
DIRECTIONAL
CONNECT
DISCONNECT
TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO
®
LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
27
NOTE
Position the NC Board exactly
as shown - ensuring when
the door is shut, the trigger is
pushed in
NOTE
Connect the 15cm Connecting
Cable from the NC Push Board
to the 6-Port Expansion Board
15cm Connecting Cable
