INSTRUCTIONS 39
DIRECTIONAL
CONNECT
DISCONNECT
TURN / FLIP NOTE ICON
POWER ON TEST
TWIST / BRAIDBEND / PIVOT
LEGO
®
LAND ROVER CLASSIC DEFENDER 90 10317 LIGHT KIT INSTALL GUIDE
30
15cm Connecting CableN/C Push Board
NOTE
Connect the 15cm Connecting
Cable to the ‘IN’ port of the NC
Push Board
NOTE
Connect the White 15cm Bit
Light to the ‘OUT’ port of the
NC Push Board
NOTE
Ensure when the back door is
closed that the trigger on the
NC Push Board is pushed
To Next Page
