LEGO T.REX BREAKOUT 76956 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 34
Legend
DISCONNECT
CONNECT /
RECONNECT
TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect the
Connecting Cable
from behind to the
8-Port Expansion
Board.
Connect the Bit
Light from behind
to the 4-port Micro
Expansion Board.
Connect the
Connecting Cable to
the 8-port Expansion
Board. Connect the
two Micro Bit Lights
to the 4-port Micro
Expansion Board.
Take a hold of
the remaining three
cables from behind
mini figure.
30
Connect the
two lights from the
electric fence to the
8-Port Expansion
Board.
