LIGHT MY BRICKS LEGO LOOP COASTER User Manual

LEGO LOOP COASTER 10303 LIGHT KIT INSTALL GUIDE
Legend
DISCONNECT
CONNECT /
RECONNECT
TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
9
Connect all the
lights underneath
the Orange plates
to Output 1 starting
from the bottom of
the pillar (e.g. first
Orange to port 1-1,
second Orange to
port 1-2)
Rotating Sequence Eects
Board
Connect all the
lights underneath the
Blue plates to Output
2 starting from the
bottom of the pillar
(e.g. first Blue to port
2-1, second Blue to
port 2-2)
5cm Connecting Cable
8-Port Expansion Board

LIGHT MY BRICKS LEGO LOOP COASTER Specifications

General

Brand	LIGHT MY BRICKS
Model	LEGO LOOP COASTER
Category	Lighting Equipment
Language	English
