LIGHT4ME FOCUS 100
Instrukcja obsługi / User Manual
9
Packaging contents
Before unpacking the device, ensure that the packaging is undamaged and contains the following
items:
moving head;
user manual;
power cable;
signal cable;
Omega mounting bracket.
Device installation
Installation notes
1. The device may be placed on a flat surface, mounted upside down on a ramp or sideways as shown
in the picture below.
2. The installation site must be stable and able to support 10 times the weight of the device. When
suspending, it is recommended to always secure the installation with a safety rope (not included)
in a suitable position so that the maximum lowering of the device is 20 cm.
Installation instructions
1. Attach the clamps (not included) to the mounting brackets.
2. Mount the brackets on the base of the device.
3. Hook the fixture to a suitable truss and fasten the clamps. Attach the safety rope (not included).
