LIGHT4ME FOCUS 100
Instrukcja obsługi / User Manual
11
Device maintenance
1. The device may only be used by qualified personnel, damage caused by improper use or attempted
repair is not covered by the warranty. There are no service parts inside the packaging, repairs may
only be carried out by authorized service center.
2. Do not allow optical components to come into contact with oil, grease or any similar liquid.
3. Regular cleaning allows of long term use and maintains proper brightness. Use a soft cloth to clean
the optical system. Also clean the fans and air vents.
Technical specification
Light source: white LED 100W
Beam angle: 15°
Color wheel: 7 color filters + open
Static gobo wheel: 7 patterns + open, Gobo Shake
Rotational gobo wheel: 6 patterns + open, Gobo Shake
Prism: 5-facet, rotational
Strobe: 1-25 flashes/sec.
Focus: electronic
Dimmer: 0-100%
DMX channel mode: 14
Operating modes: auto, sound, master/slave, DMX
Display: LCD
Cooling system: active (low noise fan)
Overheating protection function: yes
Power supply connector: PowerCon input and output
DMX signal connector: 3-pin XLR input and output
IP protection rating: IP20
Power supply: AC 100-220V, 50/60 Hz
Max. power consumption: 150W
Dimensions (DxWxH): 34 x 28 x 40 cm
Net weight: 6,5 kg
Original packaging and filling.
Menu structure
