Light4Me FOCUS 100 - DMX Structure

LIGHT4ME FOCUS 100
Instrukcja obsługi / User Manual
12
Y reversal (on/off)
Reversing Tilt movements
– on/off
XY encoder (on/off)
Automatic position correc-
tion - on/off
no DMX (on/off)
Operation in case of DMX
signal loss - on/off
screen protection (on/off)
Screen blanking – on/off
factory setting
Restoring factory settings
Manual
Operation
Manual control
System
Version
Software version informa-
tion
DMX Channel
–
System mistake record
System error log
High class
Sensor monitoring
Sensor calibration
Reset
Reset function
Gobo color adjust
Gobo and colour wheels
calibration
Chinese/English
–
Interface language selec-
tion – Chinese/English
Screen rotation
–
Reversing display position
DMX structure
DMX channel
mode (14CH)
Name
Function
Min. DMX
value
Max DMX
value
CH1
Dimmer
Dimmer – range: 0-100%
0
255
CH2
Stop/Strobe
Strobe – fast-slow
0
255
CH3
Pan
Pan movements
0
255
CH4
Tilt
Tilt movements
0
255
CH5
Pan/Tilt Speed
Pan/Tilt speed control
0
255
CH6
Prism Rt Colour
Prism rotation
0
255
CH7
Gobo
Static gobo wheel
0
255
CH8
Gobo1
Rotational gobo wheel
0
255
CH9
Gobo1_RT
Gobo rotation
0
255
CH10
Prism
Prism
0
255
CH11
Focus
Focus – range: 0-100%
0
255
CH12
Pan Fine
Detailed Pan movements
0
255
CH13
Tilt Fine
Detailed Tilt movements
0
255
CH14
Reset
Reset function
0
255
