Lightmaxx Nano Spot ARC User Manual

ENGLISH
Specifications:
Troubleshooting:
The following overview serves as an aid for quick troubleshooting. If you are unsure, contact the
manufacturer, the dealer or the corresponding specialist personnel. Never open the device on
your own!
If the specified corrections have not led to success, please contact our service staff. The contact
details can be found at www.musicstore.de
LightmaXX
Nano Spot ARC
LEDs
6x 8Watt 4in1 QCL
Colour mixture
RGBW
Dimmer
0-100%
Protection class
IP65
Power supply
AC110-220V, 50/60Hz
Power consumption
75W
Power connections
IP Power Connector/protective contact
DMX connectors
IP DMX Connector
DMX modes
4-, 8- channels
Modes of operation
DMX512, automatic mode, music control,
Master/Slave
Weight
2 Kg
Dimensions without bracket
(WxHxD)
170 x 170 x 145mm
Dimensions with bracket
(WxHxD)
170 x 208 x 145mm
Symptom
Troubleshooting
No function
Check the mains connection and the fuse
No reaction in DMX mode
Check the cable connections
Check your DMX address setting
If available, try an alternative DMX controller
No reaction in remote mode
Change the battery in your remote control
Ensure that the IR transmitter and receiver are at
close and clear distances from each other
