Lightmaxx Platinum CLS-3 QUAD - 7 Channel Mode; 16 Channel Mode

7
7 channel mode:
CH1
CH2
CH3
CH4
CH5
CH6
CH7
0-15
Master
dimmer
Flash
0-255
Slow
to fast
R
0-255
G
0-
255
B
(0-255
W
0-255
16-23 R
24-31 G
32-39 B
40-47 W
48-55 RG
56-63 GB
64-71 BW
72-79 WR
80-87 GW
88-95 RB
96-103 RGB
104-111 GBW
112-119 RGW
120-127 RBW
128-135 RGBW
136-143 Dream
Speed
control
0-255
Slow to
fast
144-151 Meteor
152-159 Fade
160-167 Change
168-175 Flow1
176-183 Flow2
184-191 Flow3
192-199 Flow4
200-207 Flow5
208-215 Flow6
216-223 Flow7
224-231 Flow8
15 color
section
15color
section
232-239 Flow9
15 color
section
15color
section
240-255 Sound
Sensitivity
0-255
16 channel mode: (Eevery 1 spot eye as 1 section, the fixture has 4 sections totally)
CH
1
CH
2
CH
3
CH
4
CH
5
CH
6
CH
7
CH
8
CH
9
CH
10
CH
11
CH
12
CH
13
CH
14
CH
15
CH
16
R1
G1
B1
W1
R2
G2
B2
W2
R3
G3
B3
W3
R4
G4
B4
W4
