Lightmaxx Vector Silent PAR ARC - DMX Operation; DMX Connectivity and Addressing; DMX Channel Functions

ENGLISH
Operating mode DMX:
Connect the DMX input of your device to the DMX output of your DMX controller, your DMX
software or the DMX output of a device already in your DMX line. Always use a DMX cable with a
110 Ohm resistor for this connection. Address the device according to your DMX configuration.
The following table shows the respective DMX modes of the individual devices with the
corresponding values and functions:
Channel
Value
Function
1
000-255
Master Dimmer
2
000-255
Red Dimmer
3
000-255
Green Dimmer
4
000-255
Blue Dimmer
5
000-255
White Dimmer
6
000-255
Amber Dimmer
7
000-255
Strobe (slow to fast)
8
000-013
Red
014-027
Green
028-041
Blue
042-055
White
056-069
Amber
070-083
Cyan
084-097
Magenta
098-100
White
101-150
Fade Colour
151-200
Switch Colour
201-250
Fade IN/OUT
251-255
No function
9
000-255
Speed (slow to fast)
