PREPARATORY WORK & ASSEMBLY
Installing the wheels
Risk of accident through malfunction of the quick release
skewer caused by improper assembly.
•Î
Observe.all.the.instructions.and.information.provided.in.the.user.
instructions.from.the.manufacturer.of.your.quick.release.skewer
.)
Make.sure.that.your.quick.release.skewer.complies.with.the.
.dimensions.specified.–see.Technical data,.page.14
.)
Follow.the.instructions.provided.by.the.manufacturer.when.
.installing.your.quick.release.skewer
.)
Mount.your.wheels.in.your.race.bike's.dropouts
.)
Make.sure.that,.after.closing,.the.levers.(
1
).are.in.a.position.that.
prevents.accidental.opening.while.riding.–.e .g .due.to.trapping .
.[
G1
]
Risk of accident by blockage of the rear wheel caused by
incorrectly positioned rear derailleur.
[
G2
]
•Î
Make.sure.that.the.derailleur.hanger.(
2
).of.your.bike.frame.is.
exactly.parallel.to.the.sprocket.set.(
3
)
•Î
Make.sure.that.the.chain.cannot.move.beyond.the.large.sprocket.
and.that.there.is.a.minimum.clearance.of.1–2.mm.between.the.
pulley.cage.(
4
).and.the.rear.wheel.spokes.(
5
)
.)
Shift.the.chain.to.the.small.chain.ring
.)
Carefully.shift.the.chain.to.the.large.sprocket
.)
Re-adjust.the.inner.limit.stop.of.your.rear.derailleur.if.the.pulley.
cage.(
4
).is.closer.than.1–2.mm.to.the.rear.wheel.spokes.(
5
)
.[
G2
]
Risk of accident due to wheels locking as a result of insuf-
ficient clearance.
•Î
Make.sure.that.the.clearance.between.the.tyres.and.rear.stays/
seat.tube.and/or.fork.blades/fork.head.is.at least 5 mm .[
G3
]
Use.narrower.tyres.if.necessary
Damage to the wheel and frame due to friction on
the seat or chain stay.
•Î
Make.sure.there.is.a.minimum clearance of 5 mm between.the.
Lightweight.
disC.and.all.rear.stays .[
G4
]
Otherwise.we.recommend.not.installing.the.Lightweight.disC.in.
that.frame!

.The.number.of.narrow.rear.frames.on.aerodynamic.race.
bike.frames.is.increasing,.which.can.cause.problems,.particularly.
with.an.asymmetric.design .
If.you.are.planning.to.purchase.a.new.race.bike.frame.with.which.
you.wish.to.use.the.Lightweight.disC,.check.with.the.frame.
.manufacturer.to.make.sure.that.your.proposed.frame.is.suitable
.)
.Check.all.measuring.points.(60.mm.….300.mm).to.make.sure.
that.there.are.the.required.clearances.between.the.rear.stays.
.–.be.particularly.careful.with.asymmetrical.rear.triangle!
ÎÎ
The.specified.dimensions.include.the.required.clearance.between.
Lightweight.disC.and.rear.stays.(5.mm) .[
G5
]
