LIGHTWEIGHT MEILENSTEIN - Installing Brake Pads; Computer Magnet Installation

PREPARATORY WORK & ASSEMBLY
23
ENGLISH
Installing the brake pads
Risk of accident caused by an insufficient braking effect or
erratic braking as a result of inappropriate brake pads.
•Î
Only.use.original.Lightweight.brake.pads,.They.are.available.from.
your.specialist.shop.or.directly.from.CarbonSports .[
H5
]
Risk of accident caused by insufficient braking effect
caused by new brake pads.
•Î
New.brake.pads.and.brake.track.areas.(
6
).only.reach.their.full.
braking.effect.during.the.bedding-in.period .[
H2
/
H3
].
Select.your.speed.to.reflect.this.during.your.first.rides
Replacing Lightweight brake pads with brake pads from
another manufacturer could cause serious damage to the brake
track areas of your Lightweight wheels.
.)
Make.sure.that.all.brake.pads.are.correctly.installed.as.follows:
ÎÎ
The.arrow.(FORWARD).should.be.facing.the.direction.of.travel.(to.
the.front)
ÎÎ
The.brake.pad.with.LEFT.labelling.must.be.installed.in.the.left-
hand.brake.shoe.(
1
),.RIGHT.in.the.right-hand.brake.shoe.(
2
) [
H1
]
.)
Slide.the.Lightweight.brake.pads.into.their.brake.shoes
.)
Shimano
®
/SRAM
®
:.Tighten.the.securing.bolts.(
3
).with.a.tightening.
torque.of.1.0–1.5 N·m (9–13 lbf·in) [
H1
]
.)
Carefully.adjust.the.brake.shoes [
H2
]
.)
Tighten.the.bolts.(
4
).on.the.brake.shoes.(
5
).with.the.correct.tight-
ening.torque [
H2
/
H3
]
Shimano
®
/SRAM
®
:.5–7 N·m (44–62 lbf·in)
Campagnolo
®
:.8 N·m (71 lbf·in)
Race bike brake shoes are gener-
ally fitted with a "wing", which acts as a guide for the wheel during
installation. Because of the aerodynamic rim profile, the wing may
come into contact with the surface of the rims when the brake pad is
50% worn. It consists of one layer of carbon and is easily damaged.
[
H4
]
•Î
Use.brake.shoes.without.wings
•Î
Check.the.distance.between.wing.and.rim.surface.at.regular.
.intervals.with.the.brake.lever.blade.set
•Î
Replace.the.brake.pads.regularly.–.at.the.latest.when.the.distance.
between.wing.and.surface.of.the.rim.is.less.than.1.mm.with.the.
brake.lever.blade.set
Computer magnet

All.Lightweight.front.and.rear.wheels.have.an.integrated.
.computer.magnet .The.magnet.symbol.identifies.the.location.of.
the.incorporated.magnet [
J1
]
.The.computer.magnets.–.without.magnet.symbol.–.
are.attached.to.a.spoke
.)
Fit.the.wheel.to.the.front.fork.or.the.rear.triangle.of.your.race.
bike
.)
Install.the.sensor.of.your.computer
.)
Align.the.computer.sensor.with.the.magnet.symbol

If.correct.alignment.of.the.front.wheel.sensor.and.Lightweight.
magnet.is.impossible.due.to.the.fork.design,.ask.your.specialist.
shop.for.an.appropriate.spoke.magnet!
Risk of accident due to spoke breakage.
•Î
Never.use.spoke.magnets.fitted.by.adjusting.screws.–.the.adjust-
ing.screw.will.cause.severe.damage.to.the.fibres.of.the.carbon.
spokes
