MAINTENANCE
29
ENGLISH
Risk of material damage.
•Î
Do.not.hold.the.rear.wheel.by.the.rim.when.removing.it
•Î
When.removing.the.wheel.grasp.it.from.below.with.both.hands.to.
the.left.and.right-hand.side.of.the.rotor
•Î
Apply.an.equal.pressure.to.the.top.at.either.side
•Î
Have.the.rotor.removed.by.a.specialist.workshop.for.bicycles.if.it.
is.not.possible.to.remove.the.hub.with.moderate.force
.)
Remove.the.hub.from.the.rear.wheel.adapter [
L3
]
.)
Remove.the.rotor.(
3
),.toothed.lock.washer.(
4
),.spring.(
5
).and.
.spacer.(
6
).from.the.axle [
L4
]
.)
Remove.the.toothed.lock.washer.(
7
).and.spring.(
8
).from.the.rotor
.)
Use.a.dry.cloth.or.brush.to.thoroughly.clean.all.components.of.
oldgrease.(including.the.inside.toothed.portions.of.the.rotor.and.
hub)
.)
Check.all.components.for.damage
.)
Apply.a.light.coat.of.grease.to.the.inner.teeth.of.the.hub.and.rotor .
[
L5
]
.)
Push.the.spacer.(
6
).and.spring.(
5
).up.to.the.mechanical.stop.on.
the.axle.bearings [
L6
]
ÎÎ
The.spring.side.with.the.larger.diameter.must.lie.flush.against.
the.bearing!
.)
Check.the.bearings.of.the.rotor.for.smooth.and.free.operation .
Have.any.defective.bearings.replaced.by.a.specialist.workshop
.)
Insert.the.spring.(
8
).into.the.rotor [
L6
]
ÎÎ
The.spring.side.with.the.larger.diameter.must.lie.against.the.
shim.of.the.rotor!
.)
Lightly.lubricate.the.toothed.lock.washers.(
4
).(
7
) [
L6
]
.)
Place.the.toothed.lock.washers.–.with.the.toothed.portions.
against.each.other.–.onto.the.axle
.)
Slide.the.rotor.over.the.axle .
Be.careful.when.installing.the.rotor .Avoid.tilting.the.components!
.)
Lightly.lubricate.the.wheel.adapter.(
9
).–.particularly.inside [
L7
]
Loss of function – rotor jams.
•Î
Do.not.replace.the.different.wheel.adapters.of.the.Campagnolo
®
,.
SRAM
®
.XDR.and.Shimano
®
.rotors
•Î
Make.sure.that.the.outer.diameter.(Ø).of.the.wheel.adapter.accu-
rately.matches.the.inner.diameter.of.the.rotor.used [
L7
]
.)
Insert.the.rear.wheel.adapter.onto.the.axle.and.press.it.by.hand.
until.it.noticeably.locks.in.place
ÎÎ
This.completes.installation.of.the.rotor

Check.the.function.of.the.freewheel.mechanism.by.turning.the.
rotor.(
3
).jerkily.and.alternately.in.both.directions [
L8
]
If.the.toothed.lock.washers.fail.to.engage.properly,.it.means.that.
either.an.excessive.amount/unsuitable.type.of.grease.has.been.
applied.or.the.freewheel.is.not.correctly.installed .
In.this.case.dismantle.the.rotor.and.proceed.as.described.above
.)
Assemble.your.cassette.–see.Installing the cassette,.page.21
