18
Especificación
Memoria para valor máximo, mínimo y última medición.
Medición de contacto del tacómetro 2,5 – 20 000 rpm
Medición de foto del tacómetro 2,5- 100 000 rpm
Velocidad de superficie 0,05 – 2 000 m/min.
(0,2 – 6560 pie/min.)
Precisión del tacómetro ± 0,05 % + 1 rpm
Precisión de la velocidad de superficie ±0,05 % + 0,1 m/min.
Lectura Revoluciones entre 2,5 -1000 rpm 0,1 rpm
Revoluciones arriba de 1000 rpm 1 rpm
Velocidades entre 0,005 -100 m/min. 0,01 m/min.
Velocidades arriba de 100 m/min 0,1 m/min.
Batería 4 piezas 1,5 V tipo AA.
Medición de contacto del tacómetro.
Escoja el adaptador apropiado para mejor aplicación contra el
centro del objeto en rotación y fije sobre el anillo de la tapa superior.
Apriete el botón frontal y seleccione CONTACT con el botón de
selección.
Apriete el botón lateral y apoye con suavidad el adaptador contra el
centro del objeto en rotación. Suelte el botón lateral cuando la
lectura estuviere estabilizada después de aproximadamente 2
segundos.
Español
