Lincat A009 - Conversion Instructions

IS 678 ECN 4993 Page 14 of 20
This appliance cannot be converted by the user.
Conversion from one gas type to another is only permitted by qualified, registered
personnel.
CONVERSION OF GAS TYPE
Convert to
Model:
J5/N
CKN88
J5/P
CKP91
J1O/N
CKN87
J10/P
CKP90
Fibre Washer
2 x FAS352
2 x FAS352
4 x FAS352
4 x FAS352
Copper Washer
2 x FAS574
2 x FAS574
4 x FAS574
4 x FAS574
Instruction
1 x IS678
1 x IS678
1 x IS678
1 x IS678
Pilot Jet
1 x JE31
1 x JE32
2 x JE31
2 x JE32
Burner Jet
2 x JE46
2 x JE13
4 x JE46
4 x JE13
Label
LA03 (Nat Gas)
LA04 (Propane)
LA03 (Nat Gas)
LA04 (Propane)
Serial Plate
LA99 (Nat Gas)
LA99 (Propane)
LA99 (Nat Gas)
LA99 (Propane)
Aeration Plate
12940
12941
12940
12941
Replace the pilot jet/s following the instructions on page 12.
At the rear of the appliance, undo the feed pipes connected to the burner inlet
elbows. Take care not to allow the pipe/nut connection to drop into the chassis.
Unscrew the elbows and remove the jets, fibre and copper washers then discard.
Unscrew the aeration plate and discard. Fit the provide aeration plate. These are
easily identified with N for Natural Gas and P for Propane etched onto the surface.
Fit new copper washers then fibre washers to the jets and tighten into the elbows.
Secure the elbows back into the burners and align with the feed pipes.
Connect the feed pipes and secure.
COMPLETION OF CONVERSION
 Remove the redundant data plate and attach the new data plate corresponding to
the new gas type.
 Remove the redundant gas type identification label and attach the new label
corresponding to the new gas type.
 Functionally operate the appliance to the new operating pressure as detailed
page4.
CONVERSION
