IS346 ECN3219
TECHNICAL SPECIFICATION
Model ECO8 ECO9
Model L3 L4
Width mm 915 1295
Depth mm 610 610
Height mm 545 545
Power Rating kW 0.35 0.4
Net weight net kg 30 40
INSTALLATION
• Remove the protective plastic coating from all metal surfaces.
• Unlatch the front flap and slide out the filters.
• Ensure that the wall on which the filtration unit is to be fitted is suitable for
supporting the appliance via the masonry plugs.
• Ensure ample room ventilation with no cross draughts (7 – 10 air changes
per hour.)
• Install the filtration unit so that there is an air space above it, with the front
lower edge of the canopy about 800mm above the cooking surface. The front
edge should overlap the cooking area by approximately 100mm.
• For safety regulations the plug or means of disconnection must always be
accessible
• Using a no.4 masonry drill, drill holes in a suitable wall as shown in Fig 1. for
the L4 and Fig 2. for the L3. Insert rawl plugs into holes. Hang the unit onto
screws in the bottom row of holes and then secure in place by screwing
through the fan covers into the top row of holes.
