IS346 ECN3219
MAINTENANCE
The parts listed below can be replaced by the user. No other regular
maintenance is required.
Lamp Bulb
• Ensure that the unit is turned off and unplugged from the mains.
• Carefully prise glass cover off using a small flat bladed screwdriver.
• Replace old bulb.
• Re-fit glass cover.
Filters
• Ensure that the unit is turned off and unplugged from the mains.
• Release the 2 suitcase latches and open the door.
• Slide filters out of unit and replace with new ones.
• Close and secure door.
SPARE PARTS
Description Part No L3 L4
On/Off switch SW66 1 1
Light Switch SW70 1 1
Light Bulb LA08 2 2
Safety Thermostat TH73 1 1
Centrifugal Fan FA25 2 3
Power Cable, Plug & Lead PL201 1 1
Suitcase Style Latch SU15 2 2
Aluminium Grease Filter FI11 2 3
Charcoal Filter FI13 2 3
Foam Pad Filter FI15 2 3
