1
1
2
Surge Suppressor
Filter/Regulator
CAUTION
The air exhaust should be
piped to an area for safe
disposition of the product
being pumped, in the event
of a diaphragm failure.
INSTALLATION GUIDE
Top Discharge Ball Valve Unit
2
150 PSI Pressure
Relief Valve
Provision For Return
To Tank
