Lincoln DOUBLE - Additional Tools Required

Page 5 of
13
QtyCode Description
A
x26
Fittings Checklist
B
x16
Spring Washer
C
x28
Washer (17x8mm)
D
E
x13
Screw (5x50mm)
F
x1
Allen Key (5mm)
Additional Tools Required
x13
Barrel Nut
QtyCode Description
Intersecting
Hole
Crosshead Screwdriver
We recommend the bed is
assembled in the room it will
be located in.
When they are supplied and are part
of the assembly of this bed, ensure
that barrel nuts are fitted the correct
way so the hole is facing towards the
intersecting hole.
x4
Screw-Washer set (M8)
x1
Allen Key (5mm)
M
N
TV INSTALLATION KIT
H
x4
Cable Clip
Cable Tie
x3
x3
K
L
x1
Allen Key (4mm)
x1
Allen Key (3mm)
(M6)
x4
x4
Counter- Sunk Screw
(M4)
Counter- Sunk Screw
Bolts (M8x30mm) for
fitting side panel (3&4)
to headboard & footboard (1&2).
Bolts (M8x20mm) for
fitting leg (11) to centre
support bar (10)
