FlowMaster™ Rotary Driven Hydraulic Pump
Page Number - 7
7.5A-18110-J00
Form 403566
Repair Parts List
(Common to all Models)
* Included in 249832 Soft Parts Kit.
1. Includes Gasket (Item 35) and O-Rings (Item 34).
Item Qty Description All Item Qty Description All
No. Models No. Models
1 2 Flat Head Screw 30 1 Housing Cover 270629
(1/4 x 1-3/4) 270635 31 1 Cover Gasket
2 2 Counter Weight 272197 (Nitrile) *
4 2 Retaining Ring 270609 32 4 Socket Head
5 1 Crankrod 270665 Screw (5/16 x 1-1/4) 270680
6 2 Retaining Ring 270608 33 1 Manifold 270700
7 1 Crank Eccentric 270727 34 2 O-Ring (Viton) *
8 1 Ball Bearing 270607 35 1 Motor Gasket *
9 1 Outlet Pin 270670 36 1 Hydraulic Motor
10 1 O-Ring (Nitrile) * (Note #1) 274054©
11
1 Plunger Tube 270729 37 2 Washer 48548
12 2 Button Head Screw 38 2 Socket Head
(1/4 x 1/2) 270634 Screw (1/2 x 1-1/4) 270658
13 2 Wrist Pin Bushing 270668 39 1 Pipe Plug (3/8 NPTF) 67417
14 1 Wrist Pin Anchor 270731 40 1 Pump Housing 270673
15 1 Backup Washer * 41 2 Backup Ring (Polyurethane) *
16 1 Cup Seal 42 2 O-Ring (Polyurethane) *
(Polyurethane) * 43 2 O-Ring (Nitrile) *
17 1 Plunger Link Rod 270728 44 2 Outlet Pin Nut 270619
18 1 Spring 270616 45 1 Bronze Bearing 270674
19 1 Ball 66010 46 1 O-Ring (Polyurethane) *
20 1 Pump Plunger 270671 47 1 Backup Washer *
21 1 Reciprocating Tube 270642 48 1 O-Ring (Nitrile) *
22 1 Cup Seal 49 1 Housing Tube 270662
(Polyurethane) * 50 1 Shovel Plug 270730
23 1 O-Ring 51 1 Retaining Ring 270705
(Polyurethane) * 52 6 Nut 51412
24 1 Pump Cylinder 270672 53 1 O-Ring 249692
25 1 Ball Cage 270675 54 6 Bolts 249693
26 1 Ball 66001 55 1 Seal 249688
27 1 O-Ring (Nitrile) * 56 1 Seal 249687
28 1 Check Seat 270664 57 6 Gasket 252986
29 6 Self-Tapping© Soft parts Kit 249832
Screw (8 x 1/2) 270633
© Indicates change
