Lincoln FlowMaster A Series User Manual

Page Number - 23
FlowMaster™ Rotary Driven Electric Pump
Maintenance and Repair
Form 402753
Repair Parts List
(Common to all Models)
Repair Parts List
(Non-common items)
* Included in 275383 Soft Parts Kit.
Note 1: Part is included in item 56a.
Item No. Qty Description All Models Item No. Qty Description All Models
1 2 Flat Head Screw 270635 32 2 Outlet, Pin-Nut 270619
2 2 Counter Weight 272197 33 2 O-Ring *
3 2 Retaining Ring 270609 34 2 O-Ring *
4 1 Crankrod 270665 35 2 Backup Washer *
5 2 Retaining Ring 270608 36 1 O-Ring 272567
6 1 Crank Eccentric 270666 37 1 Pump Shaft 272548
7 1 Ball Bearing 270607 37a 1 Woodruff Key 272560
8 1 Outlet Pin 270670 38 1 Retaining Ring 272561
9 1 O-Ring (Nitrile) * 39 1 Ball Bearing 272556
10 1 Plunger Tube See Note 2 40 1 Shaft Seal 272554
10a 1 Plunger Bushing See Note 2 41 1 Adapter Shaft 272546
10b 1 Steel Back-up Washer See Note 2 43 2 Gearbox Housing 272541
10c 1 O-ring See Note 2* 44 1 O-Ring 272544
10d 1 Retainer Clip See Note 2 45 4 Lock Washer 272566
11 2 Pivot Screw 275006 46 4 Screw 272564
12 2 Wrist Pin Bushing 275005 47 1 Gear Set 272573
13a 1 Wrist Pin Anchor 274992 48 4 Screw 272574
13b 1 O-ring * 49 1 Motor Coupler 272709**
14 1 Backup Washer * 50 1 Motor 272702
15 1 Cup Seal 51 4 Screw 272568
(Polyurethane) * 51A 3 Lock Washer 272569
16 1 Plunger Link Rod See Chart Below 52 1 Bronze Bearing 270674
17 1 Spring * 53 1 O-Ring (Polyrethane) *
18 1 Ball * 54 1 Backup Washer *
19 1 Pump Plunger & Bushing 275002 55 1 O-Ring (Nitrile) *
19a© 1 Pump Bushing See Note 3 56a 1 Housing Tube See Chart Below
20 1 Reciprocating Tube See Chart Below 56b 1 Spacer 276279
21 1 Cup Seal 57 1 Bronze Bushing Note 1
(Polyurethane) * 58 1 Shovel Plug 270707
24 1 Ball Cage 272179 59 1 Retaining Ring 270705
25 1 Ball * 60 1 Retaining Ring 272562
26 1 O-Ring (Nitrile) * 61 1 Ball Bearing 272555
27 1 Check Seat 270664 62 1 Retaining Ring 272563
28 6 Self-Threading 63 1 O-Ring 272559
Screw (#8 x 1/2) 270633 64 1 Bearing Cover 272549
29 6 Gaskets (Screw) 252986 65 4 Lock Washer 66051
30a 1 Housing Cover 275009 66 4 Screws 272557
30b 1 Dipstick 275008 67 1 Pump Housing 272540
30c 1 O-ring *
* Repair Kit 275383
Item Qty. Description Model Model
No. 85599 (120lb) 85598 (400lb)
16 1 Plunger Link Rod 270648 270645
20 1 Reciprocating Tube 275018 275158
56 1 Housing Tube 275191 275192
1 Safety Unloader 272722 ---
Note 2: Parts included in kits 275186 & 275382.
Note 3: Part is included in item 19.
