Lincoln IMPINGER 1302 - Finger Columnating Plate Identification

CounterTop - 1300 Series Ops Manual
15
FINGER COVERS ARE MATCHED AND MAY BE INSTALLED IN ANY LOCATION
NOTE: Assembly numbers are stamped on the outer edge of the finger cover.
FINGER ASSEMBLIES MUST BE INSTALLED AS SHOWN
IMPINGER
®
FINGER COLUMNATING PLATES
MODEL 1301 & 1302
SERIAL #3002168
AND ABOVE
ALL OTHER MODELS
SERIAL #3001885
AND ABOVE
MODEL 1301 & 1302
SERIAL #3002167
AND BELOW
ALL OTHER MODELS
SERIAL #3001884
AND BELOW
ASSEMBLY
NO. 1
ASSEMBLY
NO. 3
ASSEMBLY
NO. 2
ASSEMBLY
NO. 4
COLUMNATING PANEL #1368
 APPEARANCE: Perforated metal with 6 rows of larger holes.
 EFFECT: Maximum velocity and airflow. A relative comparison can
be made between a 1368/1508.
 APPLICATION: 95% of all cooking applications will use these panels
in all four fingers. An Impinger
®
CounterTop is shipped with #1368
panels in the top and bottom finger housing.
NOTE: All ICT’s will be shipped with this configuration unless you
specify otherwise.
