Lincoln SL-11 Series User Manual

18
1/4 NPT
OUTLET
10
7
6
2
1
4
SLIDE VALVE DETAIL
Item
No.
Description Qty
Part
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Adjusting Screw
Lock Nut
Adjustment Adapter
O-Ring (viton)
Washer
Packing (viton)
O-Ring (viton)
Piston Ass'y.
Plunger Spring
Fitting Ass'y.
Slide Valve Ass'y.
Spacer
Packing (Hytrel)
Back-up Ring (teflon)
O-Ring (viton)
Valve Body
Injector Body
Inlet Adapter
Spacer
1
1
1
2
1
1
1
1
1
1
1
2
2
2
2
1
1
1
1
244628
51039
244613
*
*
*
*
24462212
*
90471
*
**
*
*
*
**
244610
244611
244626
SERVICE PARTS
INJECTOR SERVICE KITS:
Part No. 244633 Injector Repair Kit
contains all normal wear parts for this
injector. Indicated with the single star
(*), above.
Part No. 244634, Valve Body Ass'y.
contains the slide valve body and spacers
for this injector. Indicated with the
double star (**), above.
12
5
Torque to
165 ft-lbs.
3
Torque to
165 ft-lbs.
Page 2
13
2 3/16"
11
19
9
5/8"
9 15/32"
2 3/4"
14
14
16
12
15
4
8
