NOTES:
DIMENSIONS IN INCHES
MATERIAL: .062 ALUMINUM
BLACK ANODIZED OR
BLACK POWDER COAT
MINIMUM BEND RADIUS
DIMENSIONS +/- .02
FBMTL-00335
70W PLASTIC CASE
BRACKET
4/7/03
0.00
.375
1.625
2.00
0.00
.25
.50
2.45 REF.
.15R (4X)
.17D (4X)
3.07
3.32
3.57
LIND ELECTRONICS, INC.
6414 CAMBRIDGE ST.
MINNEAPOLIS, MN 55426
(612) 927-6303
FAX (612) 927-7740
1.05
2.45
REF.
2.40
MIN.
