OVERVIEW
 Fire resistance classication according to EN 13501-3-2009
EI 180 S
(500 Pa)
EI 120 S
(500 Pa)
EI 90 S
(500 Pa)
EI 60 S
(500 Pa)
Rigid wall
EI 120 S Installation within vertical rigid wall
Wall minimum thickness 100 mm
Wall minimum density 550 kg/m³
Mortar or plaster putty sealing
ve (i↔o)
W -
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
EI 120S Installation within vertical rigid wall
Wall minimum thickness 100 mm
Wall minimum density 550 kg/m³
Plasterboard and rock wool 100 kg/m³ sealing
ve (i↔o)
D -
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
Flexible wall
EI 120 S Installation within vertical light wall (plasterboard)
Wall minimum thickness 100 mm
Wall rock wool minimum density 100 kg/m³
Plasterboard and rock wool 100 kg/m³ sealing
ve (i↔o)
D -
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
EI 120 S Installation within vertical light wall (gypsum blocks wall)
Wall minimum thickness 100 mm
Wall minimum density 995 kg/m³
Plasterboard sealing
ve (i↔o)
D -
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
EI 90 S Installation within vertical light wall (gypsum blocks wall)
Wall minimum thickness 70 mm
Wall minimum density 995 kg/m³
Plasterboard sealing
ve (i↔o)
D - -
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
Floor
EI 180 S Installation within oor
Floor minimum thickness 150 mm
Floor minimum density 2200 kg/m³
Mortar sealing
ho (i↔o)
W
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
EI 120 S Installation within oor
Floor minimum thickness 150 mm
Floor minimum density 650 kg/m³
Mortar sealing
ho (i↔o)
W -
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
EI 90 S Installation within oor
Floor minimum thickness 100 mm
Floor minimum density 650 kg/m³
Mortar sealing
ho (i↔o)
W - -
B x H
min 100 x 200
max 800 x 600
B x H
min 100 x 200
max 800 x 600
B X H are re damper minimum and maximum nominal dimensions (base x height) in mm
ve Vertical installation
ho Horizontal installation
(i↔o) Origin of re irrelevant
Pa Pascal of depression
E Integrity
I Thermal insulation
S Smoke seal
W Wet method sealing
D Dry method sealing
Cert. N° 1812-CPR-1045 EN 15650
