Service Training
Section 1
Päge 2
1.1 DESCRIPTION
Asynchronous traction motor (AC) mounted vertically on
the reduction gear, which is fixed on the motor unit
support.
Electrohydraulic brake mounted directly on the motor
shaft.
Motor without maintenance controlled by:
- 1 speed sensor (1B2)
- 1 temperature probe (1B6).
1.2 TECHNICAL DATA
Asynchronous motor (AC) 24 volts
Power consumption 3 KW
Maximum speed 4,865 rpm
Torque at max. speed 5.2Nm
Max. torque 35 Nm (590 rpm)
