Service Training
Section 1
Page 5
Note:
To remove the traction motor, it is recommended to first
remove the motor unit (see section 2.1.1 Removal/ins-
tallation of motor unit)
On clearing the chassis, the motor unit can be
manipulated more easily:
- Unscrew the 8 motor / reduction gear mounting bolts
(4).
- Sling the motor (1).
- Extract the traction motor from the top carefully and by
using appropriate equipment.
WARNING
Dangerous handling. The motor is heavy,
proceed with caution to remove the reduction
gear motor. It is recommended to wear gloves.
Installing the traction motor
- To install the traction motor, proceed in the reverse
order as for removal.
- Replace the O-ring (5) and grease it before refitting
the motor (1) in the reduction gear (8).
- Check the tightening torque of all the joints and con-
nections of the motor (see section 2).
CAUTION
- To prevent a short-circuit, it is important to
clamp the 3 terminals U, V, W of the traction
motor supply cables (tightening torque
9 Nm ).
- It is always possible to use an open-end
wrench to hold them while tightening.
- Make sure that all the fixtures are tightened at the
correct torque of 9.5 Nm
- Check the electrohydraulic brake air gap setting (see
section 4).
