Linear Series LS7000 - Power and Aux Connections; Wiring Diagrams

6
POWER / AUX CONNECTIONS
Pink Wire (+)
Memory to Battery
RED Wire (+)
To 12 Volt DC Power
BLACK Wire ( - ) Ground
Aux Input Cables Connect to "line outputs"
of external cassette deck, CD player, VCR or
TV. Units can be AC or DC operation.
This unit for use only with a 12 volt DC power
source with a negative ground.
